Vitradual Aluminium Facade Panel

Fairview

About this product

Vitradual Aluminium Facade Panel

TOP 3 Benefits

• NCC Compliant
• EN 15804 +A2 Environmental Product Declaration
• 15 Year Warranty

Vitradual Facade Panels are a 3mm non-combustible solid aluminium cladding with a cassette style fixing system and a PVDF coating. Vitradual Panels can be fabricated to fit individual application and is available in a variety of colour pallets. Deemed non-combustible by AS 1530.1 and classified as Group 1 in the AS 5637.1 Clause 9(n) National Construction code, this product has been third party certified as NCC compliant and is designed for multi-story buildings for residential, commercial and infrastructure projects.

Vitradual has been independently tested to the following standards: 4 point bending at third points, AS1530.3 - Fire Test on Building Materials ANSI FM 4473 Test Standard for Impact Resistance Testing of Rigid Roofing Materials, AS/NZS 4284 Waterproofing, AAMA2695-17 Voluntary Specification, Performance Requirements and Test Procedures for Superior Performing Organic Coatings on Aluminium Extrusions and Panels. Vitradual Panels have a 15 year warranty and an EN15804+A2 Environmental Product Declaration (EPD) which declares the environmental impacts of this product including water and carbon emissions.

The products are suitable for commercial projects in external applications.

Global Warming Potential
Total GWP (Global Warming Potential) in A1-A3 = 1.70E+02 kg CO2e (Anhui China); 1.75E+02 kg CO2e (Jiangsu, China)
The Functional unit is 1m2 of Vitradual with an average weight of 8.6 kg/m2

Achievements:

Health & Ecotoxicity

• No Toxicity Issues of Concern

LCA

Life Cycle Analysis - Water

• Water footprint available

Life Cycle Analysis - Resources

Life Cycle Analysis - Greenhouse Gas

• Carbon footprint available

Life Cycle Analysis - Emissions

Corporate Social Responsibility

• ≤15 year warranty
• Complies with Australian law
• Complies with relevant social and environmental laws of the country of operation
• Fit for Purpose certified
• Manufacturer take back policy
• Manufacturer take back policy (verified)

Ratings Tools

• Earthcheck
• Green Star AU - GBCA
• IS Rating - ISCA
• LEED - USGBC

Construction Code Compliance

• Australian National Construction Code

More information:

The product is GreenTag GreenRate Level A Certified under Scheme A7

EPD EN15804 + A2 2019 & ISO14025 Compliant

Global GreenTag International Standard V4.0 and V4.1

This product is available in Australia.

Rating tools relevance:

GreenRate

Green Star® Australia "Buildings" v1.0 Rating tool:

• Credit 7: Responsible Envelope

Green Star® Australia "Interiors v1.3" Rating Tools Credits:

• Credit 21: Sustainable Products

Green Star® Australia "Performance 1.2" Rating Tools Credit:

• Credit 21: Procurement & Purchasing (Refurbishment Materials)

IS® v1.2:

• Mat-2 Environmentally Labelled Products and Supply Chain

IS® Design & As-Built v2.1:

• Rso-7 Sustainability Labelled Products and Supply Chains

EarthCheck Rating Tool:

• Sustainable Materials

EN 15804 EPDs

Green Star® Australia "Buildings" v1.0 Rating tool:

• Credit 7: Responsible Envelope
• Credit 21: Upfront Carbon Emissions
• Credit 26: Life Cycle Impacts

Green Star® Australia "Interiors v1.3" Rating Tools Credits:

• Credit 19: Life Cycle Assessment

IS® v1.2:

• Mat-1 Lifecycle Impact Measurement and Reduction

IS® Design & As-Built v2.1:

• Rso-6 Material Life Cycle Measurement and Management

LEED® v4.0 for Building Design and Construction Rating Tool:
MR Credit: Building Product Disclosure and Optimization – Environmental Declarations (EN 15804 + ISO 14025 EPD Available):

• Option 2: Multi-Attribute Optimization

LEED® v4.1 for Building Design and Construction Rating Tool:
MR Credit: Building Product Disclosure and Optimization – Environmental Declarations (EN 15804 + ISO 14025 EPD Available):

• Option 2: Multi-Attribute Optimization
