Therma TR27

Kingspan Insulation

About this product

Therma TR27

TOP 3 Benefits:

• Environmental product declaration
• No Toxicity Issues of Concern
• Certified Environmental Management System

Therma TR27 is manufactured by Kingspan Insulation under an ISO 45001 certified Health and Safety Management System and ISO 14001 certified Environmental and Quality Management System.

In accordance with AS 4859.1-2018 the thermal conductivity 0.023 W/m.K and thermal resistance is 1.9 m2 K/W for Therma TR27
Spread of Flame Index is 0 to 10 and Smoke Development Index is 0 to 10 according to Australian Standard fire test AS 1530.3:1999.

Therma TR27 is suitable for providing thermal insulation in both new and refurbishment projects for commercial buildings and is backed by a 10-year warranty.

Global Warming Potential
Total GWP (Global Warming Potential) in A1-A3= 9.52 kg CO2e (TR 27)

Declared unit = The declared unit (1 m²) and conversion factors are
listed in the below.
Declared unit 1 m2
Gross density 30 kg/m3
Grammage 3.6 kg/m2
Layer thickness 0.12 m
conversion factor [Mass/Declared Unit] ( in kg/m² ) 3.6

Achievements:

Health & Ecotoxicity

• Low VOC levels
• No Toxicity Issues of Concern

LCA

Life Cycle Analysis - Water

• Water footprint available

Life Cycle Analysis - Greenhouse Gas

• Carbon footprint available

Corporate Social Responsibility

• ≤10 year warranty
• Certified Environmental Management System
• Fit for Purpose certified
• Replacement parts available

Ratings Tools

• Earthcheck
• Green Star AU - GBCA
• Green Star NZ - GBCNZ
• IS Rating - ISCA
• LEED - USGBC
• New Zealand Homestar

More information:

The product is GreenTag GreenRate Level B Certified under Scheme B4.

The scope of certification includes thickness 1m2 X 25mm, 1m2 X 30mm, 1m2 X 50mm, 1m2 X 60mm, 1m2 X 70mm, 1m2 X 80mm, 1m2 X 90mm, 1m2 X 100mm for TR27.

The products have successfully passed the relevant GreenTag Standard's Cautionary Assessment Process and no Issues of Concern or Red Light Comments exist regarding the toxicity of the products.

Global GreenTag International Standard V4.1

This product is available in Australia/New Zealand/[

Rating tools relevance:

GreenRate

Green Star® Australia "Buildings" v1.0 Rating tool:

• Credit 9: Responsible Finishes

Green Star® Australia "Interiors v1.3" Rating Tools Credits:

• Credit 21: Sustainable Products

Green Star® Australia "Performance 1.2" Rating Tools Credit:

• Credit 21: Procurement & Purchasing (Refurbishment Materials)

Green Star® New Zealand 'Design & As Built NZ' v1.1:

• Credit 21: Sustainable Products

Green Star® New Zealand 'Interiors NZ' v1.1:

• Credit 21: Sustainable Products

Green Star® New Zealand 'Performance NZ' v1.2:

• Credit 21: Procurement and Purchasing

New Zealand Homestar® v5.0 Rating Tool:

• HC7 Healthy Materials
• EN3 Sustainable Materials

LOTUS® Vietnam 'New Construction' V3:

• Sustainable Materials
• Credit H-2: Low Emission Products

IS® v1.2:

• Mat-2 Environmentally Labelled Products and Supply Chain

IS® Design & As-Built v2.1:

• Rso-7 Sustainability Labelled Products and Supply Chains

LEED® v4.0 for Building Design and Construction Rating Tool:
MR Credit: Building Product Disclosure and Optimization – Environmental Declarations (EN 15804 + ISO 14025 EPD Available):

• Option 1: Environmental Product Declarations

LEED® v4.1 for Building Design and Construction Rating Tool:
MR Credit: Building Product Disclosure and Optimization – Environmental Declarations (EN 15804 + ISO 14025 EPD Available):

• Option 1: Environmental Product Declarations

EarthCheck Rating Tool:

• Sustainable Materials

BRE Global BREEAM® International New Construction v6.0 Rating Tool:

• Hea 02 Indoor Air Quality - Emissions From Building Products

GreenTech Malaysia's MyHIJAU Ecolabelling and Green Products Database:

• All Green Building and Interiors Products
